XT Laser – Fiber Laser Cutting Machine

Fiber laser cutting machines can be divided into three levels based on power: low-power laser cutting machines, medium power laser cutting machines, and high-power laser cutting machines. The cutting efficiency of each power range of laser cutting machines is different. Small power laser cutting machines mainly focus on metal sheet cutting, medium power laser cutting machines mainly focus on medium sheet cutting, and high-power laser cutting machines mainly focus on medium thick plate cutting positions, You may find that the metal laser cutting machines in each power range are backward compatible and not upward compatible. The reason is that the higher the power, the better the efficiency of the metal sheet processed. So, how are the power ranges of the fiber laser cutting machine divided. The manufacturer of XT laser cutting machine has provided you with a reference size.

Commonly used fiber laser cutting machine power range.

The common powers of fiber laser cutting machines include 500W, 700W, 800W, 1000W, 1500W, 2000W, 3000W, etc. The maximum laser power has now exceeded 10000 watts, and it is said that the maximum is 30000 watts. However, the cutting effect still needs to be observed. The specific laser power should be selected based on the thickness of the workpiece, material, process requirements, etc. Currently, there are very few users using a 500W-800W laser cutting machine, at least 1000W. When purchasing a laser cutting machine, be sure to choose a laser cutting machine that fully meets your production needs. Laser cutting machine power.

Why is the power of laser cutting machines developing towards high power?

Generally speaking, the higher the laser cutting power, the thicker the material that can be cut, and the faster the cutting speed. But it’s not that the higher the power, the better. If it can meet the requirements of processing materials and processes, it’s good. After all, the higher the power, the higher the price.

Therefore, for enterprises that need to purchase fiber laser cutting machines, when purchasing fiber laser cutting machines for the first time, they can investigate more, ask more companies, and understand more about fiber laser cutting machines and their own needs. The materials and precision requirements you need to process are all equipped with suitable machines. Additionally, if you are unsure how to choose a laser device, you can consult our online customer service.

Power division of fiber laser cutting machine.

1. Low power consumption.

Low power is generally 300W-1500W, and this power range is 300-1000W. Due to its low power, it can only cut thin plates, so a cutting head with a focal length of 125 is usually sufficient. Short focal lengths can be quickly cut. If a 1500W factory frequently cuts 10mm or more carbon steel, it is recommended to equip a cutting head with a focal length of 150.

2. Medium power.

The average power is generally between 2000W-4000W. The 2000W power range is usually equipped with a cutting head with a focal length of 150. If you are using 3000W or 4000W and frequently process carbon steel with a size of 14mm or more, it is recommended to use a focal length of 190 or 200. Focal length. If it is processed externally and the thickness of the plate is uncertain, a focal length of 150 can be equipped, which can balance both thin and thick plates.

3. High power.

High power cutting head above 6000W. This high-power cutting head has no problems at 190 or 200 focal lengths. Due to the deep focal length, high-power cutting heads generally cut thicker plates.

The above is about the power range of commonly used fiber laser cutting machines, why the power of laser cutting machines is developing towards high power, and the classification and related analysis of the power of three types of fiber laser cutting machines. For more information, please consult the online customer service of XT Laser.
